Technical Data
| MODEL | P2 | DELIVERY n~2850 1/min | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1~ 220-240V |
3~ 380-415V |
KW | HP | Q (m3/h) | 0 | 0.6 | 1.2 | 1.8 | 2.4 | 3 | 3.6 | 4.2 | 4.8 | 5.4 |
| Q (I/min) | 0 | 10 | 20 | 30 | 40 | 50 | 60 | 70 | 80 | 90 | ||||
| 3STM3.5/6 | 3STM3.5/6 | 0.25 | 0.33 | H(m) | 25 | 25 | 24 | 23 | 22 | 20 | 18 | 15 | 11 | 8 |
| 3STM3.5/9 | 3STM3.5/9 | 0.37 | 0.5 | 38 | 37 | 36 | 35 | 33 | 31 | 27 | 22 | 17 | 12 | |
| 3STM3.5/12 | 3STM3.5/12 | 0.55 | 0.75 | 50 | 50 | 48 | 47 | 44 | 41 | 36 | 30 | 23 | 16 | |
| 3STM3.5/15 | 3STM3.5/15 | 0.75 | 1 | 63 | 62 | 61 | 58 | 56 | 51 | 45 | 37 | 28 | 19 | |
| 3STM3.5/19 | 3STM3.5/19 | 1.1 | 1.5 | 80 | 79 | 77 | 74 | 70 | 65 | 57 | 47 | 36 | 25 | |
| 3STM3.5/23 | 3STM3.5/23 | 1.1 | 1.5 | 96 | 95 | 93 | 89 | 85 | 78 | 69 | 57 | 43 | 30 | |
| 3STM3.5/27 | 3STM3.5/27 | 1.5 | 2 | 113 | 112 | 109 | 105 | 100 | 92 | 81 | 67 | 51 | 35 | |
