Dynamic Submersible pump S150C

HomeDynamic Submersible pump S150C

Technical Data

Applications

For water supply from wells or reservoir
For domestic use, for civil and industrial application
For garden use and irrigation

Operating conditions

Maximum fluid temperature up to +50ºC
Maximum sand content:0.5%
Maximum immersion:100m.
Minimum well diameter:6"

Motor and Pump

Rewindable motor or Full obturated screen motor
Three-phase:380V-415V/50Hz
Direct start(1 cable)
Star-delta start(2 cable)
Equip with start control box or digital
Auto-control box
NEMA dimension standards
Curve tolerance according to ISO 9906

Options on request

Special mechanical seal
Other voltages or frequency 60Hz

Warranty: 1 year

(according to our general sales conditions).

MODEL	POWER		Capacity and Head
380V/415V-50Hz/2850rpm	KW	HP	m3/h	0	6	12	18	24	30	36	42	48	54	60	66	72	78
380V/415V-50Hz/2850rpm	KW	HP	I/min	0	100	200	300	400	500	600	700	800	900	1000	1100	1200	1300
S150C-2	5.5	7.5	Head (m)	30	29	29	28	27	26	24	21	21	19	17	15	12	9
S150C-3	7.5	10		45	44	43	41	40	38	36	31	31	28	25	22	18	14
S150C-4	11	15		60	59	57	55	53	51	47	41	41	37	34	29	24	18
S150C-5	13	17.5		75	73	72	69	67	64	59	52	52	47	43	37	30	23
S150C-6	15	20		90	88	86	83	80	77	71	62	62	56	1	44	36	27
S150C-7	18.5	25		105	102	100	97	94	89	83	72	72	66	60	52	42	32
S150C-8	18.5	25		120	117	115	111	107	102	95	83	83	75	68	59	48	36
S150C-9	22	30		135	132	129	124	120	115	109	93	93	84	77	66	54	41
S150C-10	22	30		150	146	143	138	134	128	119	103	103	94	85	74	60	45
S150C-11	26	35		1365	161	157	152	147	140	131	113	113	103	94	81	66	50
S150C-12	26	35		180	176	172	166	161	153	143	124	124	113	102	89	72	54
S150C-13	30	40		195	190	186	180	174	166	154	134	134	122	111	96	78	59
S150C-14	30	40		210	205	200	193	187	179	166	144	144	131	119	103	84	63
S150C-15	37	50		225	219	215	207	201	191	178	155	155	141	128	111	90	68
S150C-16	37	50		240	234	229	221	214	204	190	165	165	150	136	118	96	72
