Duty Parameter
- Air flow rate: 0.02 – 0.10 m3/min
- Diameter: 10” (260 mm)
- Connection size: NPT-3/4” Male
Design Features
- Low resistance loss
- Highly tear resistant
- Anti-clogging, anti-backflow
- Ageing-resistant, anti-corrosion
Applications
- Industrial and Municipal wastewater treatment
- Gray Water Treatment
- Sludge Stabilization
- Wastewater Ozone Diffusion
- Aeration of fish ponds
Material of Construction
- MOC-Body: Reinforced ABS
- Circular Cover: Reinforced ABS
- Membrane: High Grade EPDM
Brand
- Goldentech
Single- Phase motor, 50Hz handling performance table
| Model | Material | A | B | Air Flow Rate (m3/min) | Connection Size |
| LTD- 225 | EPDM & ABS | 225 mm | 65 mm | 0.02- 0.12 | NPT- 3/4″ male |
| LTD- 260 | EPDM & ABS | 265 mm | 68 mm | 0.02- 0.10 | NPT- 3/4″ male |
| LTD- 325 | EPDM & ABS | 325 mm | 75 mm | 0.02- 0.26 | NPT- 3/4″ male |
