Duty Parameter
High quality industrial pump designed for water supply,pressure boosting, and industrial applications.
- Capacity: Up to 600m3/hr
- Head: Up to 150m
- Temp: up to 120°C
- Delivery Size: DN 32-DN 150
Design Features
- Mounting: Horizontal
- Stage: Single
- Back pullout design.
- Single-stage low-pressure centrifugal pump with axial suction, in accordance with EN 733 and ISO 5199
- Design Pressure: 16 Bar
Applications
- General industry
- Chemical & process
- Water supply
- Building service/Firefighting
- Irrigation/sprinkler system
Material of Construction
- Casing – Cast Iron
- Impeller – Cast Iron / Bronze
Brand
- Wilo
