Technical Data
Applications
- For water supply from wells or reservoir
- For domestic use, for civil and industrial application
- For garden use and irrigation
Operating conditions
- Maximum fluid temperature up to +50ºC
- Maximum sand content:0.25%
- Maximum immersion:100m.
- Minimum well diameter:6"
Motor and Pump
- Rewindable motor or Full obturated screen motor
- Three-phase:380V-415V/50Hz
- Direct start(1 cable)
- Star-delta start(2 cable)
- Equip with start control box or digital
- Auto-control box
- NEMA dimension standards
- Curve tolerance according to ISO 2548
Options on request
- Special mechanical seal
- Other voltages or frequency 60Hz
Warranty: 1 year
- (according to our general sales conditions).
| MODEL | POWER | DELIVERY & n~2850l/min | |||||||||
| 3~ 380V415V |
KW | HP | m3/h | 0 | 3 | 6 | 9 | 12 | 15 | 18 | 21 |
| I/min | 0 | 50 | 100 | 150 | 200 | 250 | 300 | 350 | |||
| 6SP17-9A | 5.5 | 7.5 | Head(m) | 97 | 96 | 94 | 90 | 85 | 75 | 63 | 45 |
| 6SP17-12A | 7.5 | 10 | 130 | 128 | 126 | 120 | 116 | 102 | 54 | 60 | |
| 6SP17-15A | 9.2 | 12.5 | 162 | 160 | 157 | 150 | 141 | 127 | 105 | 75 | |
| 6SP17-18A | 11 | 15 | 195 | 190 | 188 | 180 | 170 | 152 | 126 | 90 | |
| 6SP17-21A | 12 | 17.5 | 227 | 224 | 220 | 210 | 198 | 178 | 147 | 105 | |
| 6SP17-24A | 15 | 20 | 260 | 256 | 251 | 241 | 226 | 203 | 168 | 120 | |
| 6SP17-30A | 18.5 | 25 | 324 | 320 | 314 | 301 | 283 | 254 | 210 | 150 | |
| 6SP17-36A | 22 | 30 | 389 | 384 | 377 | 361 | 339 | 305 | 252 | 180 | |
| 6SP17-43A | 26 | 35 | 465 | 459 | 450 | 431 | 405 | 364 | 301 | 215 | |
